Bicycle technical specifications
Frame and suspension
Frame:
CROSSWAY TFS IV; aluminium; 700x50C maximum wheel size; 135x9mm; BSA
Fork:
SR Suntour NEX DS; Coil; 63 STR; 700x50C maximum wheel size
Drivetrain
Drivetrain groupset:
Shimano Essa
Speeds:
8
Speeds:
1x8
Rear derailleur:
Shimano Essa RD-U2000-8; GS
Rear shifter:
Shimano Essa SL-315-8R
Crankset:
Shimano Essa FC-U2001 40T; aluminium, Crank size: 170mm
Cassette:
Shimano CS-HG400-8; 11-45T; 8-speed
Chain:
KMC Z8
Bottom bracket:
Shimano UN101 LL123
Pedals:
VP VPE-891
Brake system
Front brakes:
Shimano MT200; hydraulic disc
Rear brakes:
Shimano MT200; hydraulic disc
Brake discs:
Front: Shimano RT10; 160 mm, Rear: Shimano RT10; 160 mm
Cockpit
Handlebar:
MERIDA COMP CC; aluminium; 680mm length; 10mm rise
Stem:
MERIDA COMP CC; aluminium; 31.8mm handlebar center diameter; 17° angle, Length: 90 mm all sizes
Grips:
MERIDA COMP TK
Headset:
MERIDA M2345, Compressor: FSA-TH-874-1, Spacers: 10mmx2
Wheels
Wheel size:
28
Rims:
MERIDA COMP TK; 17mm width; aluminium
Front hub:
Shimano TX505; 100x9mm; 32H; Centerlock
Rear hub:
Shimano TX505; 135x9mm; 32H; Centerlock
Front tire:
Kenda Ambra K1278; 700x45C; wire
Rear tire:
Kenda Ambra K1278; 700x45C; wire
Tubes:
700 x 35/43 A.V
Spokes:
Black steel
Saddle and components
Saddle:
MERIDA COMP TK
Seat post:
MERIDA COMP QR
Seat post clamp:
MERIDA COMP CC; aluminium; 30.9mm diameter; 0mm setback
Accessories
Bell:
YWS-Alloy
Weight and dimensions
Weight:
13.6 kg
Maximum load (bicycle+cyclist):
120 kg
