Bicycle technical specifications
Frame and suspension
Frame:
REACTO CF3 IV; carbon; 700x30C maximum wheel size; 100x12/ 142x12mm; BB86,5 BBR
Fork:
REACTO CF3 IV DISC; carbon; 700x30C maximum wheel size
Drivetrain
Drivetrain groupset:
Shimano Ultegra Di2
Speeds:
24
Speeds:
2x12
Rear derailleur:
Shimano Ultegra Di2
Front derailleur:
Shimano Ultegra Di2
Front shifter:
Shimano Ultegra disc Di2
Rear shifter:
Shimano Ultegra disc Di2
Crankset:
Shimano Ultegra; 52-36T, Crank size: 160 mm-3S, 165 mm-XXS/XS, 170 mm-S/M, 172.5 mm-L/XL
Cassette:
Shimano Ultegra R8101; 11-30T; 12-speed
Chain:
Shimano M6100-12
Bottom bracket:
Shimano SM-BB72-41B; Pressfit 86.5
Pedals:
Not included
Brake system
Front brakes:
Shimano Ultegra; Hydraulic disc
Rear brakes:
Shimano Ultegra; Hydraulic disc
Brake levers:
Shimano Ultegra
Brake discs:
Front: Shimano CL800; 160mm, Rear: Shimano CL800; 160mm
Cockpit
Handlebar:
Vision Metron 5D ACR EVO; carbon; 380mm (3S-XXS-XS-S); 400mm (M-L); 420mm (XL)
Stem:
Vision Metron 5D ACR EVO; carbon, Length: 90 mm-3S/XXS/XS, 100 mm-S, 110 mm-M/L, 120 mm-XL
Handlebar tape:
MERIDA ROAD Expert
Headset:
FSA ACR 3MM THINNER NECK, Compressor: SL18; Metro cap, Spacers: FSA ACR
Wheels
Wheel size:
28
Rims:
Reynolds AR 60 DB, 100x12mm front hub axle size; 142x12mm rear hub axle size; 21mm width; 60 HRI; Centerlock
Front hub:
, Axle: MERIDA EXPERT SL
Rear hub:
Axle: MERIDA EXPERT SL; including removable lever; 6/4mm allen key
Front tire:
Continental Grand Prix 5000S TR; 700x28C; fold; tubeless ready
Rear tire:
Continental Grand Prix 5000S TR; 700x28C; fold; tubeless ready
Tubes:
Ultralite 80
Saddle and components
Saddle:
Prologo Scratch M5; V-mount adapter; incl. MERIDA minitool
Seat post:
MERIDA REACTO Aero
Seat post clamp:
MERIDA Team CW; Aero shape; 15mm setback; Carbon
Accessories
Bell:
Nuvo Alloy
Weight and dimensions
Weight:
8 kg
Maximum load (bicycle+cyclist):
120 kg
