Bicycle technical specifications
Frame and suspension
Frame:
SCULTURA ENDURANCE LITE; aluminium; 700x35C max./ 700x32C (with fender) maximum wheel size; 100x12/ 142x12mm; BB86 BBR
Fork:
SCULTURA ENDURANCE CF3 DISC; carbon; 700x35C maximum wheel size
Drivetrain
Drivetrain groupset:
Shimano GRX
Speeds:
24
Speeds:
2x12
Rear derailleur:
Shimano GRX820
Front derailleur:
Shimano GRX820
Front shifter:
Shimano GRX820
Rear shifter:
Shimano GRX820
Crankset:
Shimano GRX610; 46-30T, Crank size: 165 mm-4S/3S/XXS/XS, 170 mm-S/M, 172.5 mm-L/XL
Cassette:
Shimano HG710; 11-36T; 12-speed
Chain:
Shimano M6100-12
Bottom bracket:
attached
Pedals:
Not included
Brake system
Front brakes:
Shimano GRX400; Hydraulic disc
Rear brakes:
Shimano GRX400; Hydraulic disc
Brake levers:
Shimano GRX820
Brake discs:
Front: Shimano RT54; 160mm, Rear: Shimano RT54; 160mm
Cockpit
Handlebar:
MERIDA EXPERT GRII; aluminium; (4S-3S-XXS-XS-S), 400mm (M-L), 420mm (XL)
Stem:
MERIDA TEAM CC III; aluminium; 31.8mm handlebar center diameter; -6° angle, Length: 80 mm-4S/3S, 90 mm-XXS/XS/S, 100 mm-M, 110 mm-L/XL
Handlebar tape:
MERIDA ROAD Expert
Headset:
Acros ICR MERIDA EXTERNAL neck w/diecast splitring, Compressor: SL18, Spacers: 2x10mm, 1x2.5mm
Wheels
Wheel size:
28
Rims:
MERIDA EXPERT SL III; 23mm width; aluminium; Tubeless ready (tubeless tape and valves not included)
Front hub:
Shimano HB-TC500; 100x12mm; 28H; Centerlock, Axle: MERIDA EXPERT TR
Rear hub:
Shimano FH-TC500-HM; 12-142mm; 28H; Centerlock, Axle: MERIDA EXPERT SL; including removable lever; 6/4mm allen key
Front tire:
Continental Terra Speed ProTection; 700x35C; fold
Rear tire:
Continental Terra Speed ProTection; 700x35C; fold
Tubes:
Lite 48
Spokes:
Double Butted Black stainless
Saddle and components
Saddle:
MERIDA COMP SL; 25% recycled material; V-mount
Seat post:
MERIDA EXPERT
Seat post clamp:
MERIDA COMP CC; 27.2mm diameter; 0mm setback; aluminium
Accessories
Bell:
Nuvo Alloy
Weight and dimensions
Weight:
10.1 kg
Maximum load (bicycle+cyclist):
120 kg
