Bicycle technical specifications
Frame and suspension
Frame:
SILEX CF2 II; carbon; 700x45C maximum wheel size; 100x12/142x12mm; BSA
Fork:
MERIDA SILEX II CF2; Tapered; carbon; 700x47C maximum wheel size
Drivetrain
Drivetrain groupset:
Shimano GRX
Speeds:
12
Speeds:
1x12
Rear derailleur:
Shimano GRX822
Front shifter:
Shimano GRX820
Rear shifter:
Shimano GRX820
Crankset:
Shimano GRX820; 42T, Crank size: 170 mm-XXS/XS/S/M, 172.5 mm-L/XL
Cassette:
Shimano M7100; 10-51T; 12-speed
Chain:
Shimano M6100-12
Bottom bracket:
Shimano SM-BBR60
Pedals:
Not included
Brake system
Front brakes:
Shimano GRX820; Hydraulic disc
Rear brakes:
Shimano GRX820; Hydraulic disc
Brake levers:
Shimano GRX820
Brake discs:
Front: Shimano RT64; 180mm, Rear: Shimano RT64; 180mm
Cockpit
Handlebar:
MERIDA EXPERT GRII; aluminium; 400mm (XXS-XS-S) , 420mm (M) , 440mm (L-XL)
Stem:
MERIDA TEAM CC III; aluminium; 31.8mm handlebar center diameter; -6° angle, Length: 80 mm all sizes
Handlebar tape:
MERIDA ROAD Expert
Headset:
Acros ICR MERIDA EXTERNAL neck w/diecast splitring, Compressor: SL18, Spacers: 2x10mm, 1x2.5mm
Wheels
Wheel size:
28
Rims:
Shimano WH-RX180-700C; CL; 100x12mm front hub axle size; 142x12mm rear hub axle size; 25mm width; 25 HRI; Centerlock; aluminium
Front hub:
Axle: MERIDA EXPERT TR
Rear hub:
Axle: MERIDA EXPERT TR; including removable lever; 6/4mm allen key
Front tire:
Maxxis Rambler; 700x45C; fold; TR; EXO
Rear tire:
Maxxis Rambler; 700x45C; fold; TR; EXO
Tubes:
Lite 48
Saddle and components
Saddle:
MERIDA EXPERT SL; 6% recycled and 23% nature material; V-mount; incl. MERIDA minitool
Seat post:
MERIDA EXPERT
Seat post clamp:
MERIDA TEAM SL; 27.2mm diameter; 0mm setback; Carbon
Accessories
Bell:
Nuvo Alloy
Weight and dimensions
Weight:
9.8 kg
Maximum load (bicycle+cyclist):
120 kg
